UniFi WiFi 7 AP, 6 spatial streams, Ceiling-mounted Long Range – Wirel

UniFi WiFi 7 AP, 6 spatial streams, Ceiling-mounted Long Range – Wireless Access Point

UniFi WiFi 7 AP, 6 spatial streams, Ceiling-mounted Long Range – Wireless Access Point

$242.13

SKU: NWS1022

Vendor: Unix CCTV

Type: Network

Availability: 0 left in stock

Ceiling-mounted • WiFi 7 with 6 GHz support • 6 spatial streams • 140 m² (1,500 ft²) coverage • 300+ connected devices • Powered using PoE+ • 2.5 GbE uplink

SPECIFICATIONS

Name : UniFi WiFi 7 AP, 6 spatial streams, Ceiling-mounted Long Range – Wireless Access Point
Vendor : Unix CCTV
Type : Network
Manufacturing : 2026 / 05 / 11
Barcode : U7-PRO

Click here to be notified by email when this product becomes available.

Guaranteed safe checkout:

Orders ship within 2-3 business days.

UniFi WiFi 7 AP, 6 spatial streams, Ceiling-mounted Long Range – Wireless Access Point

Description Reviews Shipping Policy

Ceiling-mounted • WiFi 7 with 6 GHz support • 6 spatial streams • 140 m² (1,500 ft²) coverage • 300+ connected devices • Powered using PoE+ • 2.5 GbE uplink

SPECIFICATIONS

Overview
Dimensions	Ø206 × 46 mm(Ø8.1 × 1.8")
WiFi Standard	WiFi 7
Spatial Streams	6
Coverage Area	140 m² (1,500 ft²)
Max. Client Count	300+
Uplink	2.5 GbE
Mounting	Ceiling, Wall(Pro Mount Included)
Power Method	PoE+
Performance
MIMO	6 GHz: 2 × 2 (DL/UL MU-MIMO) 5 GHz: 2 × 2 (DL/UL MU-MIMO) 2.4 GHz: 2 × 2 (DL/UL MU-MIMO)
Max. Data Rate	6 GHz: 5.8 Gbps (BW320) 5 GHz: 4.3 Gbps (BW240) 2.4 GHz: 688 Mbps (BW40)
Antenna Gain	6 GHz: 5.8 dBi 5 GHz: 6 dBi 2.4 GHz: 4 dBi
Max. TX Power	6 GHz: 23 dBm 5 GHz: 26 dBm 2.4 GHz: 23 dBm
Max. BSSIDs	8 per Radio
Supported Data Rates	802.11: be (WiFi 7): 7.3 Mbps to 5.8 Gbps (MCS0 – MCS13 NSS1/2, EHT 20/40/80/160/240/320) 802.11ax (WiFi 6/6E): 7.3 Mbps to 2.4 Gbps (MCS0 – MCS11 NSS1/2, HE 20/40/80/160) 802.11ac (WiFi 5): 6.5 Mbps to 1.7 Gbps (MCS0 – MCS9 NSS1/2, VHT 20/40/80/160) 802.11n: 6.5 Mbps to 300 Mbps (MCS0 – MCS15, HT 20/40)
Features
Wireless Meshing	✓
Band Steering	✓
802.11v BSS Transition Management	✓
802.11r Fast Roaming	✓
802.11k Radio Resource Management (RRM)	✓
Advanced Radio Management	✓
Passpoint (Hotspot 2.0)	✓
Private Pre-Shared Key (PPSK)	✓
WiFi Speed Limiting	✓
Client Device Isolation	✓
WiFi Schedules	✓
RADIUS over TLS (RadSec)	✓
Dynamic RADIUS-assigned VLAN	✓
Captive Hotspot Portal
Voucher Authentication	✓
Payment-Based Authentication	✓
External Portal Server Support	✓
Password Authentication	✓
Guest Network Isolation	✓
Custom Branding Landing Page	✓
Hardware
Max. Power Consumption	21W
Supported Voltage Range	44—57V DC
Networking Interface	(1) 1 / 2.5 GbE RJ45 port
Weight	680 g (1.5 lb)
Management	Ethernet
Enclosure Material	Polycarbonate, metal
Mount Material	Stainless steel (SUS304), galvanized steel (SGCC)
LEDs	System: White / Blue
Channel Bandwidth	HT 20 / 40, VHT 20 / 40 / 80 / 160, HE 20 / 40 / 80 / 160, EHT 20 / 40 / 80 / 160 / 240 / 320 (MHz)
NDAA Compliant	✓
Certifications	CE, FCC, IC, Anatel
Operating Frequency	US / CA: 2400 ~ 2472 MHz U-NII-1: 5150 ~ 5250 MHz U-NII-2A: 5250 ~ 5350 MHz U-NII-2C: 5470 ~ 5725 MHz U-NII-3: 5725 ~ 5850 MHz U-NII-5 to U-NII-8 : 5925 ~ 7125 MHz Worldwide: 2400 ~ 2483.5 MHz 5150 ~ 5725 MHz 5925 ~ 7125 MHz
Ambient Operating Temperature	−30 to 40° C (−22 to 104° F)
Ambient Operating Humidity	5 to 95% noncondensing
Software
Application Requirements	UniFi Network: Version 8.0.28 and later
